CU Medical Systems iPAD AED NF1200 Defibrillator

Specifications:

Physical: Dimensions 81Wx220Lx 281H (mm). Weight 2.2kg (Including the battery pack and pads).

Environmental

Operational Status
(The device is in emergency use)
Temperature:
0°C ~ 40°C (32°F ~ 104°F)
Humidity:
5% ~ 95% (non condensing)
Altitude
0 to 15,000 feet (operational and storage)
Drop
Withstands 1.2 meter drop to any edge, corner, or surface
Vibration
Operating: Meets EN1789 random and swept pine, road ambulance specification in operating and standby modes
Sealing
IEC 60529: IP55
ESD
Meets IEC 61000 4 2:2001
EMI (Radiated)
Meets IEC 60601 1 2 limits, method EN 55011:1998 +A1:1999+A2:2002, Group 1, Class B,
EMI (Immunity)
Meets IEC 60601 1 2 limits, method EN 61000 4 3:2001Level 3 (10V/m 80MHz to 2500MHz)

Defibrillator

Operating Mode
Semi automated
Waveform
e cube biphasic (Truncated exponential type); impedance compensated
Output Energy
200J nominal into a 50 Ohm load
Charge Control
Controlled by an automated patient analysis system
Charging Time
Within 10 seconds of the voice prompt “Shock Advised”.
